15 Watt T8 LED; CCT Selectable; Medium bi-pin base; 50000 Hours; Type A/B; Ballast Bypass or Direct : X3QPQ

Return to Catalog

Part Number: X3QPQ / Vendor ID #: 27

15 Watt T8 LED; CCT Selectable; Medium bi-pin base; 50000 Hours; Type A/B; Ballast Bypass or Direct

$21.70

Item Sales Info

Add To Wishlist

Compare Item

Availability

Manufacturer has 18 items available.This Item has been Discontinued. Please verify product pricing and availability with vendor prior to submitting any orders.

Dimensions

Width: 1.00"

Product Overview

15 Watt T8 LED; CCT Selectable; Medium bi-pin base; 50000 Hours; Type A/B; Ballast Bypass or Direct Replacement; Single or Double Ended Wiring; Glass with PET coating

Standard Information

Category:

Lamps

Subcategory:

LED Lamps

Lumens:

1601-2600

Kelvin:

3501-4000

Wattage:

15w

Refinement Options

Category:

LED

Sub-Category:

LED T8

Volts:

120V-277V

Bulb Dimmable:

Yes-Dimmable

Bulb Hours:

50000

Bulb Kelvin:

3500K/4000K/5000K

Bulb Shape:

Diameter:

EA Length:

Harmonized Codes:

8539.52.0051

Length:

47.78

Lumens:

2150L/2200L/2200L

Shap Carton Width:

Ship Carton Height:

Ship Weight:

0.65

Warranty:

5 Year Limited - T8 LED Bulbs

Weight:

0.55

BAA Compliant:

Ballast Bypass Direct:

Dual

Ballasting Requirements:

Ballast required (Type A) or Ballast Bypass (Type B)

Beam Spread:

180

Bulb ANSI Base:

G13

Bulb Base:

Medium Bi Pin

Bulb Finish:

White

Burning Position:

Universal

Carton Cubic Feet:

0.0278

Cartons Per Unit:

CCT Selectable:

Yes

CEC:

Exempt - Base Not Regulated

CEC Terse:

Lawful for sale in California

CEC Web Text:

Lawful for sale

Color Temprature:

Neutral White to Natural Light

Country Of Origin:

China

CRI:

Dimmable Function:

Only in Type A mode; Check Ballast MFG for Dimmer Compatibility

DLC Approved:

Yes

DLC Classification:

Standard

DLC ID:

S-X87CKG

DLC Primary Use:

Dual Mode Internal Driver (UL Type A and Type B)

Efficacy:

143.33/145.00/146.67 LPW

Enclosed Fixture Use:

Yes

FCC Compliant:

Yes

Feature 1:

CCT Selectable - 3500K/4000K/5000K

Feature 2:

Direct replacement for fluorescent T8 lamps

Feature 3:

Ballast compatible or ballast bypass installation

Feature 4:

NSF Certified - P.E.T. coated, shatter resistant glass tube

Feature 5:

Compatible with select emergency backup and dimming ballasts

Feature 6:

Dimmable

Feature 7:

Rated for 50,000 hours

Flourescent Equivalent:

55W

Housing Color:

White

Incandescent Equivalent:

75W

Installation Notes:

Not for use in vapor tight fixtures.

IOT Enabled:

IP Rating:

IP20

JA8 Compliant:

Lamp Ballast Type A/B/C:

Type A/B

Lamp End Type:

Single Ended;Double Ended

Lamp Filament:

LED

Lens Finish:

Frost

Lens Material:

Glass

Location Rating:

Damp

Long Description:

SATCO|NUVO's S11763 premium LED T8 dual mode lamps offer the most versatility of any linear replacement lamp on the market. This lamp is compatible with ballasts and in ballast bypass systems with single or double-ended wiring to maximize ease of insta

Material:

Glass / Plastic

Nominal Length:

NSF Approved:

Yes

Operating Frequency:

50/60Hz

Operating Temp:

-20C (-4F) to +45C (+113F)

Order In Multiples Of:

Pack Type:

Sleeve

Power Factor:

0.9

Quantity In Pack:

RoHS Compliant:

Yes

Romance Copy:

SATCO|NUVO's premium LED T8 dual mode lamps offer the most versatility of any linear replacement lamp on the market. These lamps are compatible with ballasts and in ballast bypass systems with single or double-ended wiring to maximize ease of installat

SDS class:

LED_Lamp

Shatter Proof Text:

PET Coated

Short Description:

15T8/LED/48-CCT/DM/BP-DR

Style:

Utility

Surge Protection:

Built-in-surge protection - 0.7KV

Technology:

LED

Title 20 Compliant:

Title 24 Compliant:

Wattage Selectable:

Watts:

15W
