82 Watt; 8 ft. LED; Linear Strip Light; CCT Selectable; 120-347 Volt; White Finish : A36HD

Return to Catalog

Part Number: A36HD / Vendor ID #: 81

82 Watt; 8 ft. LED; Linear Strip Light; CCT Selectable; 120-347 Volt; White Finish

$292.50

Item Sales Info

Add To Wishlist

Compare Item

Availability

Manufacturer may be Out Of Stock.

Dimensions

Height: 3.27"

Width: 2.95"

Product Overview

82 Watt; 8 Foot LED; Linear Strip Light; CCT Selectable; 120-347 Volt; White Finish

Standard Information

Category:

Undercabinet

Subcategory:

Strip Lights

Finish:

White

Style:

Traditional

Option:

LED

Prop 65

Lumens:

3300+

Kelvin:

4001-4500

Refinement Options

Category:

Linear Strip

Sub Category:

Strip Fixture

Style:

Utility

Additional Info:

Other DLC Listings: PLTRVDFB3IUR, Standard, Direct Linear Ambient Luminaires.

Avg Rated Hours:

50000

Bulb Shape1:

Integrated LED

Bulb Type1:

LED

Color Temperature:

Neutral White to Daylight

Dimmable:

Yes-Dimmable

Each Height:

5.32

Each Length:

98.03

Each Width:

5.2

Length:

Lumens:

10400L-10800L

Tariff Code:

9405.11.6010

Warranty:

5 Year Limited - Fixtures

Amps:

0.683-0.236A

ANSI Base:

Integrated

BAA Compliant:

Beam Angle:

120

B_U_G_Rating:

B3-U4-G3

CA Prop-65:

Lead

CCT Selectable:

Yes

CEC:

T20 Exempt - Fixtures Not Regulated

CEC Terse:

Lawful for sale in California

CEC Web Text:

Lawful for sale

Connection:

Hardwire

Country Of Origin:

Vietnam

CRI:

Dimmable Down To:

100 to 10 percent

Dimmable Function:

0-10V Dimming Only

DLC Classification:

Premium; Standard

DLC Primary Use:

Stairwell and Passageway Luminaires; Direct Linear Ambient Luminaires

Each Cube:

1.5694

Each Quantity:

Efficacy:

126.83/129.27/131.71 LPW

FCC Compliant:

Yes

Feature 1:

CCT Selectable 3500K/4000K/5000K

Feature 2:

120V-347V

Feature 3:

3KV Surge Protection

Feature 4:

0-10V Dimmable

Feature 5:

80 CRI

Feature 6:

50,000 Hours

Feature 7:

5 Year Warranty

Finish Family:

White

Flicker Free:

Yes

Has Driver:

Yes

HID Equiv:

150W

Incandescent Equivalent:

550W

Indoor Outdoor:

Indoor

Installation Notes:

Maximum connected units are 7. If dimming, the dimmer max load will dictate how many units can be on the run/control.

IOT Enabled:

IP Rating:

IP20

JA8 Compliant:

Lens Finish:

White

Lens Material:

Polycarbonate (PC)

Long Description:

Introducing SATCO|NUVO's newest addition to our LED strip lights. SATCO|NUVO's 65-703 is a new cULus listed 82-Watt high lumen 8-foot strip addition is CCT selectable (3500K/4000K/5000K) just like its wattage and CCT selectable counter parts (65-70

Material:

Steel

Mounting Diameter:

4.75

Mounting Procedure:

Ceiling/Wall

NSF Approved:

Operating Frequency:

50/60Hz

Operating Temp:

-20C (-4F) to +60C (+140F)

Pack Type:

Box

Photocell:

Optional Add-On

Power Factor:

0.9

Quantity In Pack:

R9 Value:

Replaceable Light Source:

RoHS Compliant:

Yes

Romance Copy:

Introducing SATCO|NUVO's newest addition to our LED strip lights. This new cULus listed 82-Watt high lumen 8-foot strip addition is CCT selectable (3500K/4000K/5000K) just like its wattage and CCT selectable counter parts (65-701 and 65-702.) It has a

Safety Listing:

cULus - Listed

SDS class:

LED_Fixture

Short Description:

8'LINEAR STRIP WHITE FINISH

Sloped Ceiling Compatible:

Yes

Specification Notes:

Add on sensors, 86-202 and 86-211, are only rated for 120-277 Volt

Temperature (CCT):

3500K/4000K/5000K

Title 20 Compliant:

Title 24 Compliant:

Total Harmonic Distortion:

15%

Wattage Selectable:

Weight Lb.:

6.84
